| DESIGN | ASME B16-34 |
| VALVE SIZE | 15 to 350 mm ( 1/2” to 14” ) |
| RATING | ANSI 150 to 600 Equivalents to BS, DIN, IS, JIS, etc. |
| FACE TO FACE | ISA S.75.03 up to 600# |
| END CONNECTION | Flanged – 15mm to 350mm ( 1/2” to 14” ) Screwed – 15mm to 50mm ( 1/2” to 2” ) |
| BODY MATERIALS | Carbon Steel, Chrome-moly Steel, Stainless Steel,Monel, Alloy20, Hastelloy B/C, Duplex Stainless Steel, Aluminum Bronze, PP, PTFE etc. |
| BONNET | Standard upto 250°C Normalizing (Finned) between 250°C to 500°C Extended cold service – 20°C to – 100°C Cryogenic – 100ºC to – 250ºC Bellows seals. |
| GLAND PACKING | Grafoil / PTFE V Rings, Low Emission |
| TRIM DESIGNS | Skirt Guided. Linear, Pressure Balance. |
| TRIM MATERIALS | Stainless Steel, Alloy20, Monel, Duplex Stainless Steel,13% Chrome Steel Hastelloy B/C, Stellite (Alloy 6 ) |
| CHARACTERISTICS | Equal Percentage, Linear and Quick Opening. |
| SEAT LEAKAGE | As per ANSI/FCI-70-2 Class III. IV, V and VI (STANDARD LEAKAGE RATES) Metal to Metal Seating Class IV, Less than 0.01% of rated Cv. Metal to Soft Seating – Bubble tight (Zero Leakage) |
| ACTUATOR TYPE | Diaphragm, Piston or Electric. |
| ACTUATOR ACTION | Direct / Reverse Acting. |
| DIAPHRAGM | Nitrile / Neoprene |
| SPRING RANGES | 3 – 15 PSIG ( 0.2 – 1.0 Kg/cm² ) 6 – 30 PSIG ( 0.4 – 2.0 Kg/cm² ) |
| AIR SUPPLY | 20 – 35 PSIG (1.4 – 2.5 Kg/cm² ) |
| AIR CONNECTION | 1/ 4” or 1/ 2” NPT |
| ACCESSORIES | Valve Positioner – Pneumatic , Electro Pneumatic, Smart Positioner. Instruments- Airset, Solenoid Valve, Air Lock, Volume Booster, Position Transmitter, Limit– Proximity Switches etc. Features- Top or Side Mounted handwheel, Limit Stops Removable Blind Head, Steam Jacketing, etc. |
